Humminbird HELIX 7 CHIRP MEGA SI GPS G4 Chartplotter/Fishfinder

Fish smarter

The Humminbird HELIX 7 CHIRP MEGA SI GPS G4 Chartplotter/Fishfinder features MEGA Side Imaging, MEGA Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS and Humminbird Basemap built-in. An upgraded high-definition 7' display will give you the best view of the many pre-loaded split screen view options so that you'll never miss a fish.

Humminbird HELIX 7 CHIRP MEGA SI GPS G4 Chartplotter/Fishfinder Features:

• Keypad control
• MEGA Side Imaging
• MEGA Down Imaging
• Dual Spectrum CHIRP sonar
• Internal GPS and Humminbird Basemap
• Premium Chart Compatible
• AutoChart Live
• Includes control head, transom-mount transducer, power cable, gimbal mounting bracket and mounting hardware

Humminbird HELIX 7 CHIRP MEGA SI GPS G4 Chartplotter/Fishfinder Specifications:

• Product Code: 411620-1
• Display size - Diagonal: 7in (17.78cm)
• Display Pixel Matrix: 1024H x 600V
• Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging, MEGA Side Imaging
• Sonar-Coverage: 20, 42, 60 and (2) 86 @ -10dB
• Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP
• CHIRP - Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz)
• Sonar-Frequencies Supported: 50/83/200/455/800 kHz and 1.2 MHz
• Depth-Sonar: 1,200 ft (standard transducer), 3,500 ft (optional 50 kHz)
• CHIRP - Imaging-Frequencies Supported: 455 kHz (440-500 kHz), MEGA DI (1075-1150 kHz), MEGA SI (1075-1150 kHz)
• Depth-Down Imaging: 400 ft (455 kHz), 75 ft (MEGA)
• Range-Side Imaging (Side-To-Side): 800 ft (455 kHz), 250 ft (MEGA)
• Interface: Keypad Control
• Memory Card Slot: Single Micro SD
• Compatible With: AIS, AutoPilot, Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI
• Power Draw: 800 mA
• Power Input: 10.8-20 VDC
• Power Output Peak-to-Peak: 4000 Watts
• Power Output RMS: 500 Watts
• Screen Snap Shot: Included
• Sonar Recording: Included
• Mount-Standard: Gimbal
• Mount-Standard Size: 10.54' W x 5.8' H x 3.68' D
• Mount-Optional Size: 10.54' W x 5.44' H x 1.13' D
• Transducer Mount Location: Transom
• GPS Chartplotting: Included
• GPS Trackplotting: Included
• LakeMaster Compatibility: Yes
• Coast Master Compatibility: Yes
• Navionics Gold/HotMaps Compatibility: Yes
• Navionics Platinum + Compatibility: Yes
• Platinum Compatibility: Yes
• Heading Sensor GPS Compatibility: Yes
• Upgradable Software: Yes
• View Preset Keys: No
• X-Press Menu System: Yes
• Custom Digital Readout: Yes
• Custom View Selections: No
• Display Colors Grayscale: 16-Bit
• Display Size: : 5' - 7'
• Speed: Included
• Temperature: Built In
• Temperature Alarm: Yes
• Temperature Graph: Yes
• Transducer Included: XNT 9 HW MSI 150 T
• HDMI Compatible: No
• MEGA Live Compatibility: No
