Shakespeare Marine 5242A Classic VHF Antenna 36in

Shakespeare Style 5242-A
3 ft. (0.91 M) VHF Marine Band 3dB

Low-profile end-fed -wave with standard duty whip

This legacy style is coming back due to customer request. A convenient press-and-twist bayonet fitting makes attaching or removing its stainless steel whip quick and easy. The bayonet has been re-designed and improved for extra convenience.

Stainless steel whip (36in)
Whip is user replaceable.
L-shaped bracket included for mounting
One section
Best applications include: bass boats and center console fishing boats; for small to medium and similar types of vessels.

Shakespeare 5242-A Specifications
Band: VHF Marine Band
Antenna Gain: 3dB
Max. Input Power: 50 watts
SWR: nominally 1.5:1 at 156.8 MHz
Bandwidth: 7 MHz within 2.0:1 VSWR
Ferrule: Chrome plated brass cannister
Polarity: Vertical
Impedance: 50 Ohms
DC Ground: No DC Ground - The antenna will read open on continuity test.
Shakespeare
Limited Warranty: 2 years
