Triducer Multisensor - 3 sensors in one!
The Airmar B744V Bronze Thru Hull Transducer provides three sensors namely depth, speed, and temperature all in one thru-hull housing! The B744V’s patented valve assembly prevents water from rushing into the hull when the insert is removed for cleaning or storage. The innovative housing design allows the TRIDUCER Multisensor to be fully recessed into its custom High-Performance Fairing. The end result is a streamlined installation. At speeds above 30 knots (34 MPH), the B744V will produce clear images and solid bottom tracking! This transducer is ideal for inshore or coastal fishing in shallow to medium depths, slow trolling, structure fishing, drifting, and deep water lake fishing. This unit is ideal for all 600W fishfinders and requires only a single hole in the hull.
Airmar B744V Bronze Thru Hull Transducer Features:
- Depth, speed, and temperature in one housing
- Greatly improved high-speed performance at both 50 kHz and 200
kHz when installed with a high-performance fairing
- Patented self-closing sea valve reduces water flow into the
hull when paddlewheel insert is removed
- Speed Operating Range: 1 knot to 45 knots (1 MPH to 52
MPH)
- Fins on sides of paddlewheel cavity provide improved accuracy
in cross flow conditions
- Fits boat size of up to 14m (45’)
- Rating: 600w
- Beamwidth: 50 kHz—45° ; 200 kHz—12°
- Maximum Depth Range: 50 kHz—235 m to 353 m (800’ to 1,200’) ;
200 kHz—118 m to 206 m (400’ to 700’)
- 12 m (39’) cable with OEM connector
- Designed for use on all fiberglass and wood boat types—power
and sail
- Weight: 2.5kg (5.5lb)
- Hull Deadrise Angle: Up to 24° with fairing
- Bronze housing
- AIRMAR B744V For Lowrance Models: HDS-10, HDS-5, HDS-5x, HDS-7, HDS-8, LCX-110C, LCX-111C HD, LCX-112C, LCX-113C HD, LCX-17M, LCX-20C, LCX-25C, LCX-26C HD, LCX-27C, LCX-28C HD, LCX-38C HD, LMS-335C DF, LMS-337C DF, LMS-339C DF iGPS, LMS-480, LMS-525C DF, LMS-527C DF iGPS, X105C DF, X107C DF, X126DF, X136DF, X-515C DF, X59DF , SIMRAD NSE
Hull Material Recommendations:
- Fibreglass - Plastic, Bronze or Stainless Steel Housing
- Metal - Stainless Steel Housing
- Wood - Bronze or Stainless Steel Housing
