Airmar XSONIC TM150M CHIRP Transom Mount Transducer 300w

When performance matters most, we've got you covered

the Airmar XSONIC TM150M CHIRP Transom Mount Transducer is an economical Chirp transducers designed for offshore fishing and freshwater anglers. Operating at a frequency range of 95-155 kHz, the TH150 reveals fish in shallow, murky waters at medium depths (up to 2,500 feet) along with ultra-clear target resolution. This transom mount transducer is best suited for small and trailered boats where a thru-hull installation is not practical.

XSONIC Connector
Airmar XSONIC Transducers come with the new 9-Pin Black XSONIC connector. This transducer is compatible with Lowrance HDS Gen3, HDS Carbon and Elite-7 ti models. No need to mix, match or splice. Just plug and go!

Airmar XSONIC TM150M CHIRP Transom Mount Transducer Features:

• One broadband transducer covers up to 117 kHz of bandwidth – greater opportunities to detect fish in the water column

• Superior resolution – precise separation between baitfish and gamefish represented on the display with crisp images

• Enhanced bottom fishing – resolve targets close to the bottom or near structure/wrecks

• Amazing detail – recognise haloclines and thermoclines

• Improved signal to noise ratio – find fish and track bottom at high boat speeds

• Simple to install and ideal for small trailered vessels where a thru-hull may interfere with loading

• No holes in the hull

• Great performance at boat speeds below 30 knots

• Easy maintenance and low-cost replacement

• Depth and water temperature sensor

• Ideal for inshore or coastal fishing in shallow to medium depths

• Freshwater anglers will see fish holding close to structures and suspended fish

• Track bottom at higher boat speeds

• More coverage under your boat delivers wider arches and 26° to 17° beamwidths

• Cover the medium frequency range—CHIRPs from 95-155kHz to provide 60 kHz of total bandwidth from one transducer

• Available in plastic transom-mount with transom bracket and hardware and with a custom transom housing and cover (TM150M)

• Also available as thru-hull installation (B150M)

• Hull Type: Fiberglass, wood or metal

• 1 internal ceramic


Airmar XSONIC TM150M CHIRP Transom Mount Transducer Specifications:

• Weight: 0.45 kg (1.1 lb)

• Hull Deadrise: 2° to 20°

• Acoustic Window: Urethane

• Medium:
  95 kHz to 155 kHz
  26° to 17° beamwidth

• Maximum depth 600 ft

• 60 kHz of total bandwidth from one transducer


Note: Not recommended for inboard powerboats and stepped hull.
